E-FOX BOOST
Our E-FOX BOOST front thru axle, designed for use on our e-bikes, is made entirely by CNC with the most advanced precision mechanics techniques and a careful selection of the best materials.
Unlike the XC model, the axle in question has been designed to withstand greater stresses and weights, while maintaining all the characteristics of our thru axles.
The tightening system takes place through a T25 torx insert in grade 5 titanium, a high quality material renowned for its extraordinary resistance.
This makes it not only innovative, but also absolutely unique compared to any other current offering on the market.
All our pins come with hexagonal recessed insert made of the best aluminum alloy, and its function is twofold:
It makes the Thru Axle completely hermetic, preventing any type of impurity from getting in, but above all, it provides the possibility of unscrewing or screwing our axle from both sides of the fork.
All our products undergo a chemical surface treatment that increases their resistance to wear and weather, ensuring a longer lifespan.
Characteristics:
pin body material 7075-T6 Aluminum
clamping system by means of Grade 5 Titanium Screw Torx T25
Consult the technical data sheets in the table to view all the measurements
| Standard | Diameter (mm) | Length (mm) | Thread Pitch (mm) | Weight (grams) | Download |
|---|---|---|---|---|---|
| E-FOX BOOST | 15 | 155.5 | 1.5 | 51 |  |
